Industrial Dust Collection System for Central Filtration Solutions – Modular – Pulsatron Compact TV
Industrial Dust Collection System designed to filter dense dry fumes and dust generated during polishing, buffing, and deburring operations in compliance with OHS standards. The Jet Pulse self-cleaning system enables continuous operation with minimal maintenance downtime. Filter replacement intervals are indicated via warning lights on the PLC control panel. Thanks to its modular design, the system can be combined to form central dust collection systems for different airflow requirements.
| Dimensions | 850 × 930 × 2815 mm |
|---|---|
| Airflow m³/h | 1500 m³ – 2500 m³2000 m³ – 4000 m³5000 m³ – 5800 m³4500 m³ – 5500 m³6000 m³ – 7000 m³7000 m³ – 8000 m³8000 m³ – 9000 m³9000 m³ – 11000 m³11000 m³ – 14000 m³ |
Please be advised: By communicating via WhatsApp, you are considered to have accepted the relevant legal obligations and GDPR responsibilities. Your mobile operator may apply charges for WhatsApp usage. FRESHWELD® cannot be held liable for any potential issues that may arise.
Technical Specifications Table
| PULSATRON TV | AIRFLOW | STATIC PRESSURE |
MOTOR POWER |
SURFACE AREA |
FILTRATION SPEED | CONNECTIONS (mm) |
DIMENSIONS (mm) |
|||
|---|---|---|---|---|---|---|---|---|---|---|
| FW CODE | (m³/h) | (Pa) | (kW) | (m²) | (m²/m³/minute) | INLET | OUTLET | W | L | H |
| 511PC01504 | 1500 – 2500 | 2700 – 2100 | 3 | 40 | 1,04 | Ø250 | Ø300 | 930 | 850 | 2815 |
| 511PC02004 | 2000 – 4000 | 3200 – 2100 | 4 | 40 | 1,66 | Ø250 | Ø300 | 930 | 850 | 2815 |
| 511PC05004 | 5000 – 5800 | 1800 – 1500 | 4 | 80 | 1,21 | Ø320 | Ø300 | 930 | 850 | 2815 |
| 511PC04508 | 4500 – 5500 | 3500 – 3000 | 7,5 | 80 | 1,14 | 2 x Ø250 | 405 x 362 | 930 | 1700 | 2425 |
| 511PC06008 | 6000 – 7000 | 2000 – 1650 | 5,5 | 80 | 1,45 | 2 x Ø250 | 405 x 362 | 930 | 1700 | 2425 |
| 511PC07008 | 7000 – 8000 | 2800 – 2650 | 7,5 | 80 | 1,66 | 2 x Ø250 | 405 x 362 | 930 | 1700 | 2425 |
| 511PC08012 | 8000 – 9000 | 2650 – 2150 | 7,5 | 120 | 1,25 | 3 x Ø250 | 405 x 362 | 930 | 2550 | 2425 |
| 511PC09016 | 9000 – 11000 | 2450 – 2200 | 2 x 5,5 | 160 | 1,14 | 4 x Ø250 | 2 x (405 x 362) | 930 | 3400 | 2425 |
| 511PC11016 | 11000 – 14000 | 3050 – 2800 | 2 x 7,5 | 160 | 1,45 | 4 x Ø250 | 2 x (405 x 362) | 930 | 3400 | 2425 |
The Pulsatron Compact Industrial Dust Collection System is designed to efficiently filter dense dry fumes and dust from polishing, buffing, and deburring applications in compliance with OHS standards. Featuring a non-disposable cartridge filter with Jet Pulse compressed air cleaning, it ensures long service life with minimal maintenance. The programmable PLC control panel enables reliable operation, while the modular design allows integration into central dust collection systems for varying airflow requirements.
Areas of Use
- Cartridge Filter Central Dust Collection System, Pulsatron Compact.
- Designed for filtering fumes and dust generated during industrial processes.
- Industrial Cartridge Dust Collection System.
- Suitable for welding, grinding, sandblasting, laser cutting, plasma cutting, and polishing applications.
- Ideal for foundries and large-scale dust-intensive production facilities.
Main Application Areas
- Metal Polishing
- Polishing Operations
- Surface Finishing
- Laser Cutting Systems
- Deburring Operations
- Welding Fume Extraction
- Grinding
- Foundry Applications
- Chemical Applications
- Epoxy Coating
- Pharmaceutical Applications
- Plastic Material Processing
- Dusty Material Handling
- Plasma Cutting Applications
Features
- Guaranteed emission value of ≤ 5 mg/Nm³.
- Low noise level of 68 – 75 dBA.
- Jet-pulse automatic filter cleaning system enables self-cleaning with compressed air.
- The modular central filter system design adds a clean and professional appearance to your facility.
- Engineered with airflow capacities ranging from minimum 1,000 m³/h up to maximum 14,000 m³/h.
Options
- Silencer
- 3-color (Red – Yellow – Green) LED filter contamination indicator
- Integrated HEPA filter for absolute filtration
- Automatic dust discharge system
- Mechanical shaker system for filter cleaning
- Start & Stop or frequency-controlled electrical control panel
- Horizontal spark arrestor cyclone for special applications
