Industrial Dust Collection, Fume and Aerosol Filtration Compact Hall Ventilation – Novus Compact F
FRESHWELD x NOVUS Airtower Compact F is a compact industrial dust collection indoor air purification unit designed to efficiently separate industrial dust, fumes, aerosols and fine particles through a configurable one to four-stage filtration system with minimal space requirements.
| Weight | 175 kg |
|---|---|
| Dimensions | 738 × 674 × 2308 mm |
| Use Case | Ground MountedWall Mounted |
Please be advised: By communicating via WhatsApp, you are considered to have accepted the relevant legal obligations and GDPR responsibilities. Your mobile operator may apply charges for WhatsApp usage. FRESHWELD® cannot be held liable for any potential issues that may arise.
Technical Specifications Table
| NOVUS COMPACT F | TYPE OF USE | MOTOR POWER | FILTRATION STAGES | NOISE LEVEL | AIRFLOW | DIMENSIONS (mm) | WEIGHT | |||
|---|---|---|---|---|---|---|---|---|---|---|
| FW CODE | (kW) | 1° | 2° | dB(A) | (m³/h) | W | L | H | (kg) | |
| 7150F0GR04 | GROUND | 3,9 | 1 x Bag Filter – 6,2m² | 1 x F9 – 30m² | < 71 | 4250 | 674 | 738 | 2308 | 175 |
| 7150F0WM04 | WALL MOUNTING | 3,9 | 1 x Bag Filter – 6,2m² | 1 x F9 – 30m² | < 71 | 4250 | 674 | 738 | 2308 | 175 |
Industrial Dust Collection FRESHWELD x NOVUS Airtower Compact F, Multi-Stage and Compact Indoor Air Filtration System
- Designed for the separation of industrial dust, fumes, aerosols and fine particles from ambient air.
- Ensures high-efficiency indoor air purification with minimal space requirements.
In industrial production environments, dust, fume and aerosol emissions directly impact workplace air quality. Therefore, the filtration system must be both highly efficient and space-saving to ensure sustainable and safe air management.
Despite its compact design, the FRESHWELD NOVUS Airtower Compact F delivers advanced industrial dust collection performance with cutting-edge filter technology, ensuring effective air circulation and continuous clean air within production areas. As the slimmest model of the AIRTOWER series, it has been developed to improve indoor air quality without requiring additional ventilation infrastructure.
Main Application Areas
- Industrial manufacturing facilities
- Welding fume extraction areas
- Processes generating dust and fine particles
- Production environments with aerosol emissions
- Enclosed spaces with limited floor area
- General factory indoor air quality improvement applications
Features
- Configurable with one to four-stage filtration structure according to application needs.
- Pre-filtration stage utilizes ISO ePM10 60% or ISO ePM1 80% class filter bags for safe and cost-effective filtration.
- Main filter can be selected in different classes up to H14 HEPA depending on emission type.
- For welding fume applications, an additional metal mesh pre-filter positioned before the main filter provides extra protection.
- Filter pads at the outlet grilles support homogeneous distribution of clean air and prevent external dust ingress when the unit is not operating.
- Compact housing design ensures minimal footprint and easy integration into existing production areas.
Options
- Different filter configurations based on emission type
- High-efficiency HEPA filter options (up to H14)
- Pre-metal mesh protection filter for welding applications
- Custom filter combinations tailored to indoor air quality requirements
