High-Volume Mobile Welding Fume Filtration Tower for Small Spaces NOVUS GO F
Has been specially developed for uncomplicated and user-friendly operation in small work spaces. Thanks to its heavy-duty castors and ergonomic push handle, the unit can be easily transported to the next job location with minimal effort. Designed as a fully automatic, programmable, plug & play welding fume filtration tower, the GO F variant delivers efficient extraction of welding and soldering fumes while ensuring reliable air purification performance in industrial environments.
| Weight | 245 kg |
|---|---|
| Dimensions | 1100 × 1020 × 2080 mm |
| Airflow m³/H | 5000m³10000m³ |
Please be advised: By communicating via WhatsApp, you are considered to have accepted the relevant legal obligations and GDPR responsibilities. Your mobile operator may apply charges for WhatsApp usage. FRESHWELD® cannot be held liable for any potential issues that may arise.
Technical Specifications Table
| NOVUS GO F | AIRFLOW | MOTOR POWER | FILTRATION STAGES | TOTAL FILTRATION AREA | DIMENSIONS (mm) | WEIGHT | ||||
|---|---|---|---|---|---|---|---|---|---|---|
| FW CODE | (m³/h) | (kW) | 1° | 2° | 3° | W | L | H | (kg) | |
| 711NVSGO05 | 5000 | 3,9 | 1 x M6 – 9m² | 1 x F9 – 33m² | 3 x G4 – 4m² | 54m² | 1100 | 1020 | 2080 | 245 |
| 711NVSGO10 | 10000 | 2 x 3,9 | 2 x M6 – 9m² | 1 x F9 – 55m² | 3 x G4 – 4m² | 85m² | 1771 | 1760 | 2080 | 550 |
Novus GO F Tower Fully Automatic, Programmable, Plug & Play Mobile Welding Fume Ventilation System
The High-Volume Mobile Welding Fume Filtration Tower for Small Spaces NOVUS GO F has been specially developed for uncomplicated and user-friendly operation in small workspaces. Thanks to its heavy-duty castors and ergonomic push handle, the unit can be easily transported to the next job location with minimal effort. Designed as a fully automatic, programmable, plug & play welding fume filtration tower, the GO F variant delivers efficient extraction of welding and soldering fumes while ensuring reliable air purification performance in industrial environments.
- Designed for production areas where large workpieces are manufactured and local extraction systems such as articulated arms cannot be implemented.
- Suitable for emissions generated during various technical processing operations, including welding fumes, dust particles, aerosols, and gaseous air contaminants.
Welding operations are rarely performed in the same position and at the same working height. Therefore, effective welding fume filtration requires flexible extraction technology and high airflow performance.
The FRESHWELD NOVUS GO F Airtower is specifically engineered for variable welding stations, large production areas, and high-tonnage factories with intensive robotic welding operations. Operating on a “Plug & Play” principle, it functions without additional ducting, discharge, or ventilation connections and is ready for immediate commissioning at the desired location.
Position the unit, connect electrical power and compressed air, and your industrial ventilation system will be operational within a short time—experience improved indoor air quality and workforce productivity within one hour.
Main Application Areas
- Processes generating heavy soot and welding fumes
- Dust and particulate-producing manufacturing operations
- Armored and military vehicle manufacturing facilities
- Large-scale industrial workspaces
- Facilities with intensive robotic welding systems
- Plants generating aerosol emissions
- Automobile, truck, and bus manufacturing plants
- Defense industry production facilities
- Agricultural machinery manufacturing plants
- Heavy industrial machinery production facilities
- Foundry and metal processing plants
- Iron and steel industry facilities
- Aerospace manufacturing and maintenance facilities
- Home appliance manufacturing plants
- Hardware production facilities
- High-tonnage production environments
Features
- The FRESHWELD Novus GO F Central Industrial Filtration Tower is suitable for workspaces of all scales.
- Operates as a standalone welding fume filtration tower and does not require additional hoods, ductwork, or chimney connections.
- Requires only an electrical connection and a compressed air connection for automatic filter cleaning.
- Manufactured from advanced impact-, scratch-, and heat-resistant polycarbonate construction.
- Airflow capacity can be optimized between 5,000 m³/h and 10,000 m³/h, engineered according to your facility requirements (see Technical Specifications table).
Options
- Optional production in accordance with IFA W3 standards,
- Remote control capability,
- Integrated air quality sensor enabling automatic start/stop operation based on pollution levels, supporting reduced energy consumption and carbon footprint,
- Efficiency package for additional energy savings and noise reduction,
- Enhanced safety package against flying sparks and fire risks,
- Activated carbon filter media for gas purification and odor control,
- Reduced operating costs with nano-fiber layered filter cartridges.
